Sponsler, Inc. Model T675 Flow Totalizer Technical Information Pg. 17
3.3.1.1 – Flowmeter Size
Automatically programs the corresponding minimum and maximum flow range, ratemeter bar graph display limits
and alarm points. Depress the corresponding number for the turbine size in left column, entry is automatic.
Example: 2” turbine; <7>.
************ Flowmeter Size ************
Current setting = 7
1 – 1/2”
2 – 5/8”
3 – 3/4”
4 – 1.0”
5 – 1-1/4”
6 – 1-1/2”
7 – 2.0”
8 – 3.0”
9 – 4.0”
Enter setting? (ESC to exit)?
Flowrate chart by turbine size:
Flowmeter
Size
Min Flow
(GPM)
Max Flow
(GPM)
½” 1 10
5/8” 2 15
¾” 3 30
1” 4 60
1 ¼” 6 90
1 ½” 8 130
2” 15 225
3” 40 650
4” 75 1250
3.3.1.2 – Alarm and Timer settings
Permits setting the following parameters. Depress the corresponding category number in the left column, entry is
automatic.
******** Alarm & timer settings ********
1 – Totalize during alarm (0=NO, 1=YES)
2 – Pump cooldown timer (0=OFF, 1=ON)
3 – Pump cooldown delay (sec)
4 – Intermittent temp. tolerance (sec)
5 – Pump on during alarm (0=NO, 1=YES)
6 – Count while temp fail (0=NO, 1=YES)
Enter setting (ESC to exit)?
