Sponsler, Inc. Model T675 Flow Totalizer Technical Information Pg. 10
3.2 – ADJUSTMENT MODE:
Permits the programming of sealable Calibration and Configuration parameters. Selecting this option will cause a prompt
for a passcode. Once the passcode is entered properly access is permitted. Refer to page 9 for complete Adjustment
programming instructions. If a T675-PEM (Programming enable module) is installed, the Adjustment Mode can only be
accessed by first removing the safety wire secured T675-PEM located on the bottom right of the T675 enclosure.
The Adjustment Mode contains the programmable Calibration and Configuration parameters. These sealable
parameters are passcode protected because they alter the calibration and/or billing accuracy. Depress the
corresponding category number in the left column, entry is automatic.
************ Adjustment mode ***********
1 – Calibration
2 - Configuration
Enter setting (ESC to exit)?
3.2.1 – Calibration
Allows setting the following parameters. Depress the corresponding category number in the left column, entry is
automatic.
***** Adjustment mode - Calibration ****
1 – Avg. Kfactor
2 – Linearizer table
3 – Linearizer (0=OFF, 1=ON)
Enter setting (ESC to exit)?
3.2.1.1 – Avg. Kfactor
Allows entry of the average Kfactor in pulses per gallon. This Kfactor is used for all calculations when the linearizer
function is turned “Off”.
Example: Insert Kfactor = 148.914; <148.914>
************* Avg. Kfactor *************
Current setting = 148.914
Enter setting (ESC to exit)?
