Sponsler, Inc. Model T675 Flow Totalizer Technical Information Pg. 15
Display for Unit of measure Option 3
************** Temperature *************
Current setting = 3
1 – Kelvin
2 – Centigrade
3 – Fahrenheit
Enter setting (ESC to exit)?
Note:
3.2.2.4 – Digits right of decimal
Changing the Engineering Unit will clear any existing delivery total. Accumulative totalizer will
automatically convert to the new engineering unit.
Selects the number of digits to the right of the decimal point (0 – 3) in the delivery totalizer quantity. Depress the
desired number, entry is automatic.
Example: Select 2 digits to right of the decimal point (DP); <2>
******** Digits right of decimal *******
Current setting = 0
Enter setting (ESC to exit)?
Note:
3.2.2.5 – Use dual coil
Changing the setting will clear any existing delivery total.
Allows the user to select the number of signal inputs the T675 processes. Selection of the dual coil engages
additional signal processing logic to capture input data from 2 sources. Additionally, detection logic is activated to
detect reverse flow, missing or extra pulses and inhibit them from corrupting the delivery total.
Example: Enable the dual coil function; <1>
** Use dual coil (0=NO, 1=YES) **
Current setting = 0
Enter setting (ESC to exit)?
3.2.2.6 – Use printer checking
Enables the T675 to detect that the printer is online and enabled for delivery.
Example: Enable the printer checking; <1>
** Use printer checking (0=NO, 1=YES) **
Current setting = 0
Enter setting (ESC to exit)?
