20
Configure LCR - General Setup
Sale #
This field indicates the current sale number. The Sale #
is used to track the number of transactions the Lectro-
Count processes. This number will increment each time
a delivery is started. Click on the green lock indicator to
open a Field Edit Window.
Enter the starting number for Sale # and click on Write to
LCR. The LectroCount will use this as the starting value
for Sale # and increment by 1 each time a delivery is
started. Once Sale # reaches 999999, it will return the
count to zero and resume counting from 1.
NOTE: This field can only be adjusted when the Lectro-
Count selector switch is in the calibration position.
Ticket
Ticket is similar to the Sale #. Ticket will increment each
time the LectroCount prints a ticket. If multiple or dupli-
cate tickets are used for transactions, the ticket number
will increment more than the Sales #.
Click on the green lock indicator to open a Field Edit
Window. Enter the starting number for Ticket and click
on Write to LCR. The LectroCount will use this as the
starting value for Ticket and increment by 1 each time a
delivery ticket is printed. Once Ticket reaches 999999, it
will return the count to one and resume counting from 1.
NOTE: If zero is entered for Ticket, it will not print on the
delivery ticket and it will not increment. This field can
only be adjusted when the LectroCount selector switch
is in the calibration position.
Print Gross Param?
Print Gross Param? is used to enable or disable the print-
ing of gross volume and compensation parameter on the
ticket if the product is temperature compensated. In many
applications this is required. Check local Weights &
Measures requirements.
Click on the green lock indicator to open a List Box Win-
dow. Select “NO” if it is not desired to print the gross
volume and compensation parameter on the ticket. Se-
lect “YES” if it is desired to print the gross volume and
compensation parameter on the ticket. Click on Write to
LCR to accept the selection.
NOTE: This field can only be adjusted when the Lectro-
Count selector switch is in the calibration position.
Vol Corrected Msg?
Vol Corrected Msg? is used to enable or disable the print-
ing of the base temperature of net deliveries on the de-
livery ticket. In many applications, this is required. Check
local Weights & Measurements requirements.
Click on the green lock indicator to open a List Box Win-
dow. Select “NO” if the volume corrected message is
NOT to be printed on the delivery ticket. Select “YES” to
have the volume corrected message printed on the de-
livery ticket. If “YES” is selected, the LectroCount will
print a message on the delivery ticket indicating that the
delivery volume has been corrected to a specified base
temperature.
If the base temperature is in °C, the message will read:
“TEMPERATURE VOLUME CORRECTED TO 15 °C”
If the base temperature is in °F, the message will read:
“TEMPERATURE VOLUME CORRECTED TO 60 °F”
NOTE: The base temperature for Linear C and Linear F
can be set to a value other than 15 or 60. This field can
only be adjusted when the LectroCount selector switch
is in the calibration position.
Pulse Out Edge
All LectroCount registers feature a calibrated pulse out-
put which cycles once per least significant unit of deliv-
ery. The Pulse Out Edge field allows the LectroCount to
synchronize the calibrated pulse output waveform with
the requirements of an external counter. Depending on
the manufacturer, some counters may increment on the
rising pulse edge of the waveform, some on the falling
pulse edge. Refer to the manufacturer’s manual to de-
termine the specific requirements.
Click on the green lock indicator to open a List Box Win-
dow. Select “RISING” for the rising edge of the pulse
output. Select “FALLING” for the falling edge of the pulse
output. Click on Write to LCR.
NOTE: This field can only be adjusted when the Lectro-
Count selector switch is in the calibration position.
