Installation and Maintenance Manual
HySecurity Hydraulic Swing Gate Operator
Smart Touch Controller Menu Guide for Swing Gates
To gain access to the User Menu, press the Menu button when the gate is stopped. The LCD
will scroll through key several items, then stop at the close timer setting [Ct ].
User Menu Options Default Description
U1 [Ct 0] Close timer setting 0 0 = Close timer off or 1 – 99 seconds
U2 [hC 0] Momentary Close 0 0 = momentary, 1= Constant hold PB required
U3 [ho 0] Momentary Open 0 0 = momentary, 1= Constant hold PB required
U4 [AP 0] AC Power loss function 0 0 – 3 (0 =Type A, 1 = B, 2 = C, 3 = D)
U5 [ro 0] Radio control option 0 0 = Open only, 1 = Adds close ability when full open
U6 [bF 2] Warn before operate 2 0 =off, 1 = Buzzer alerts 3 seconds before + in motion, 2 =
Buzzer alerts 3 sec before + 2 seconds in motion
U7 [FA 0] Forced open Alert and
automatic gate reposition 0 0 = off, 1 sound buzzer (2 pulses/sec) if forced
open for more than four seconds, time out in 30 Sec
U8 [dA 0] Drift Closed Alert and
automatic gate reposition 0 0 = off, 1 sound buzzer (2 pulses/sec) if drift closed and
cannot reopen within four seconds.
U9 [PE 0] Photo Eye Align Mode 0 0= off, 1 = on (auto off when close limit triggered)
U10 [CL 0] Clock set (24 hour type) 0 0= display, 1= set mins, 2= set hours, 3= day, 4= month
U11 [Ld 5] LCD Contrast set 5 1 - 9 = Adjusts contrast of the display
U12 [dS 0] Data Log (New Gen only) 0 0 = Std. 1 = Extended (reset to 0 in 24 hr) (V4.xx software)
To access Installer Menu, press the Open & Reset buttons together while in the User Menu.
Installer Menu Options Default Description
I1 [uC 0] Set UL Usage Class 0 0 = Gate disabled, Set Class 1 through 4 use
I2 [bu 0] Choose Buzzer 0 0 = Buzzer not set, 1 = Freq 1, 2 = Freq. 2
I3 [Fd 0] Load Factory Defaults 0 0 = User settings, 1 = Load defaults (resets full menu)
I4 [dg 0] Set Master/Slave type 0 0 = Solo operator, 1 = Slave unit, 2 = Master unit
I5 [Ch 0] Set AC Charger or Solar 0 0 = DC + AC charger, 1 = DC + Solar charger
I6 [Fo 0] Enable Fire Dept. Open 0 0 = input disabled, 1 = enabled
I7 [oC 0] Enable Emergency close 0 0 = input disabled, 1 = enabled
I8 [SE 2] Inherent Sensor sens. 3 1 = Maximum sensitivity, 9 = Lowest sensitivity
I9 [SS 0] Inherent Sensor function 0 1 = stop only (note, functions in usage class 4 only)
I10 [LC 0] Leaf delay Close 0 0 = none (1-7) ½ second steps (Master/Slave only)
I11 [Lo 0] Leaf delay Open 0 0 = none (1-7) ½ second steps (Master/Slave only)
I12 [rt 0] Maximum run timer 0 0 = 60 Seconds max run, 1 = 300 Seconds max run
I13 [EC 0] PEC reverse to open 0 0 = Close eye stops only, 1 = 2 sec reverse to open
I14 [EO 0] PEO reverse to close 0 0 = Open eye stops only, 1 = 2 sec reverse to close
I15 [gr 0] Edge reverse to open 0 0 = Edge reverses fully open, 1 = Edge reverses for 2 sec
I16 [Sr 1] IES reverse to open 1 0 = IES reverses fully open, 1 = IES reverses for 2 sec
I17 [PC 0] Set PEO/ PEC – NO/NC 0 0 = Normally Open PE output, 1 = N.C. (Supervised)
I18 [gC 0] Set Edge input – NO/NC 0 0 = Normally Open Edge output, 1 = Normally Closed
I19 [tC 1] Time clock/ Interlock input 1 0 = select Time Clock, 1 = select Open Interlock
I20 [dt 0] Disable Free Exit/Close Tmr 0 0 = disable Free Exit, 1 = disable Close Timer
I21 [or 1] OOLD detector function 1 0 = pause closing only, 1 = enable reversing to open
I22 [ir 1] IOLD detector function 1 0 = pause closing only, 1 = enable reversing to open
I23 [hd 1] SLD Shadow detector funct 1 0 = Hold open only, 1 = Hold closed + Hold open
I24 [dL 1] Vehicle detector logic 1 1 = Std, 2 = Close timer counts down even with loops active
I25 [r1 0] User relay 1 option 1 0 = disabled, 1 – 24 = see relay output options
I26 [r2 0] User relay 2 option 6 0 = disabled, 1 – 24 = see relay output options
I27 [r3 0] User relay 3 option 1 0 = disabled, 1 – 24 = see relay output options
I28 [tL 0] Gate Open alert 2 0 = 0 sec, 1= 15s, 2= 45s, 3= 75s, 4= 105s, 5= 135s
I29 [Lt 0] Loitering alert 3 0 = 0 sec, 1= 15s, 2= 45s, 3= 75s, 4= 105s, 5= 135s
I30 [SA 0] System Address 0 0 = no network, 1-99 = network ―drop‖ address
I31 [ELd0] Test factory ELD* 0 0=Run, 1=show freq, 2=show call level 0-7, 3=set freq 1-4
I32 [iLd0] Test factory IOLD* 0 0=Run, 1=show freq, 2=show call level 0-7, 3=set freq 1-4
I33 [oLd0] Test factory OOLD* 0 0=Run, 1=show freq, 2=show call level 0-7, 3=set freq 1-4
I34 [SLd0] Test factory SLD* 0 0=Run, 1=show freq, 2=show call level 0-7, 3=set freq 1-4
