Smart Touch Controller Menu for Hydraulic Swing Gates
Initial Power Up – When power is turned on, the display will disclose the software revision:
Display Revision Number 2s delay Displays software version Number, ex. [h3.02]
System Data and accessing the User Menu Settings:
If the gate is stopped in normal mode, pressing of the Menu button accesses the User Menu. After the
menu button is pressed, the LCD will scroll the system data in the table below. The scrolling display
stops at the close timer setting, which is the beginning of the User Menu. To exit the Menu Mode, the
display must not be blinking, then simply pressing the Menu button will return the display to the Run
Mode and re-enable the controls. The menu mode will also automatically return to the Run Mode if there
is no activity for two minutes.
Data Displayed in Scroll Time Description
S1 [SLAu] or [LEAd] 2s SLAVE Operator or LEAd Operator (master)
S2 [ot 2] Gate type (1-5) 2s Operator type: 1=HSG, 2=HRG, 3=HVG, 4=HTG
S3 [uC _] UL usage class (1-4) 2s Installer setting of usage class: type 1-4
S4 [d___] 24VDC Buss Voltage 2s Actual VDC buss voltage
S5 [CC__] Life cycle counter 2s High digits of 6 digit life cycle counter
S6 [____] Life cycle counter 2s Last 4 digits of 6 digit life cycle counter
Read through the options available in the User Menu and the Installer Menu on the next page and you
can see that the functions of this gate operator can be configured to suit most any specific need. Once
you have learned to navigate the menus, and how to change a menu setting, the full range of features
and choices of the Smart Touch Controller are available to use. The User Menu contains the basic
configuration items and the Installer Menu contains the more advanced menu items.
User Menu Options Default Description
U1 [Ct 0] Close timer setting 0 0 = Close timer off or 1 – 99 seconds
U2 [hC 0] Momentary Close 0 0 = momentary, 1= Constant hold PB required
U3 [ho 0] Momentary Open 0 0 = momentary, 1= Constant hold PB required
U4 [AP 0] AC Power loss function 0 0 – 3 (0 =Type A, 1 = B, 2 = C, 3 = D)
U5 [ro 0] Radio control option 0 0 = Open only, 1 = Adds close ability when full open
U6 [bF 2] Warn before operate 2 0 =off, 1 = Buzzer alerts 3 seconds before + in motion,
2 = Buzzer alerts 3 sec before + 2 seconds in motion
U7 [FA 0] Forced open Alert and
automatic gate reposition 0 0 = off, 1 sound buzzer (2 pulses/sec) if forced
open for more than four seconds, time out in 30 Sec
U8 [dA 0] Drift Closed Alert and
automatic gate reposition 0 0 = off, 1 sound buzzer (2 pulses/sec) if drift closed and
cannot reopen within four seconds.
U9 [PE 0] Photo Eye Align Mode 0 0= off, 1 = on (auto off when close limit triggered)
U10 [CL 0] Clock set (24 hour type) 0 0= display, 1= set mins, 2= set hours, 3= day, 4= month
U11 [Ld 5] LCD Contrast set 5 1 - 9 = Adjusts contrast of the display
U12 [dS 0] Data Log (New Gen only) 0 0 = Std. 1 = Extended (reset to 0 in 24 hr) (V4.xx software)
These Notes Refer to the Menu Above:
S1 Appears only if the operator is configured as a master or a slave unit
U1 Close timer setting does not appear when set for constant contact close to function
U4 Power loss function only appears if factory has provided DC type operator
U6 We strongly advise never disabling the Warn Before Operate buzzer.
