GF Signet 2250 Hydrostatic Level Sensor User Manual
Page 8
Ordering Information
Accessories and Replacement Parts
2250 Hydrostatic Level Sensor
Mfr. Part No.
Code
Description
5523-0322
159 000 761
Sensor cable (per ft.). 3 conductor plus shield, 22 AWG (black/red/white/shield)
3-9000.392-1
159 000 839
Liquid tight connector kit, NPT (1 pc.)
3-9000.392-2
159 000 841
Liquid tight connector kit, PG 13.5 (1 pc.)
3-8050
159 000 184
Universal mount kit
3-8052
159 000 188
¾ in. Integral mount kit
3-8050-1
159 000 753
Universal Mount w/Junction terminals
3-8052-1
159 000 755
¾ in. Integral mount w/Junction terminals
3-0250
159 001 538
USB to Digital (S
3
L) Confi guration/Diagnostic Tool
Mfr. Part No.
Code
Description
3-2250-11U
159 001 242
0 to 0.7 bar (0 to 10 psi), Digital (S
3
L), ½ in. union, ¾ in. PVC-U Union
3-2250-11L
159 001 241
0 to 3.4 bar (0 to 50 psi), Digital (S
3
L), ½ in. union, ¾ in. PVC-U Union
3-2250-21U
159 001 248
0 to 0.7 bar (0 to 10 psi), 4 to 20 mA, ½ in. union, ¾ in. PVC-U Union
3-2250-21L
159 001 247
0 to 3.4 bar (0 to 50 psi), 4 to 20 mA, ½ in. union, ¾ in. PVC-U Union
3-2250-11U-1
159 001 478
0 to 0.7 bar (0 to 10 psi), Digital (S
3
L), ½ in. union, Metric PVC-U Union
3-2250-11L-1
159 001 479
0 to 3.4 bar (0 to 50 psi), Digital (S
3
L), ½ in. union, Metric PVC-U Union
3-2250-21U-1
159 001 482
0 to 0.7 bar (0 to 10 psi), 4 to 20 mA, ½ in. union, Metric PVC-U Union
3-2250-21L-1
159 001 483
0 to 3.4 bar (0 to 50 psi), 4 to 20 mA, ½ in. union, Metric PVC-U Union
Georg Fischer Signet LLC, 3401 Aero Jet Avenue, El Monte, CA 91731-2882 U.S.A. • Tel. (626) 571-2770 • Fax (626) 573-2057
For Worldwide Sales and Service, visit our website: www.gfsignet.com • Or call (in the U.S.): (800) 854-4090
For the most up-to-date information, please refer to our website at www.gfsignet.com
3-2250.090 Rev. E 06/13 English
© Georg Fischer Signet LLC 2013
Sensor Part Number
3-2250 Hydrostatic Level Sensor
Sensor Output
-1 Digital (S
3
L), 10 m (32.8 ft.)
-2 Current (4 to 20 mA), 10m (32.8 ft.)
Threaded Connection
1 ½ in. union connector
Operating Pressure Range
U 0 to 0.7 bar (0 to 10 psi)
L 0 to 3.4 bar (0 to 50 psi)
PVC-U Union Connection
- ¾ in. socket
-1 Metric pipe connector
3-2250 -1 1 U
Example Part Number
