PROGRAMMER’S REFERENCE MANUAL
Label layout definition commands
Page 29
Defining a line/box field
A line/box field appears as a black area on the label or as a frame window. Diagonal lines
can be made using Syntax II.
Syntax I !F B
Syntax II !F B D
Note! For diagonal lines must x0 > x1 and y0 > y1
Defines the direction of printing as the "up" direction of the printed character.
One upper-case character (N, E, S, or W). Since there is no inherent ‘up’ or ‘down’
in a black box this parameter is just a convenience which allows lines and boxes
to be specified the same way text and bar code fields are specified.
The baseline of the field, in
1
/
10
mm.
The position, in
1
/
10
mm
The alignment relative to the position. One upper-case character.
L = left end of the field aligned at p.
R = right end of the field aligned at p.
C =
t
he field is centered around p.
The height of the box or width of the line, in
1
/
10
mm
The width of the box or length of the line, in
1
/
10
mm
The width of the border of a window frame, in
1
/
10
mm. If this parameter is omitted
or set to 0 a filled (solid) box will be created.
Source y-coordinate.
Source x-coordinate.
Line width, in
1
/
10
mm.
Destination y-coordinate.
Destination x-coordinate.
