66

Appendix A – Specifications

Media / Ribbon

Media Types

Roll-Fed, Die-Cut, Continuous, Fan-Fold

Max. Media Width

4.4 inches (110mm)

Min. Media Width

0.75 inches (19mm)

Max. Print Width

203 DPI Models: 4.25 inches (108mm)

300 DPI Models: 4.12 inches (106mm)

Print Length Range

.236 – 99 inches (6 - 2514mm)

Minimum Label Height

Tear: 0.5 inches (12mm)

Peel: 1.0 inches (25mm)

Cut: 1.18 inches (30mm)

Media Thickness Range

.0025 - .01 inches (.064 - .254mm); up to .005 inches (.127mm) with

optional Cutter

Media Supply Roll Capacity

Pro Models: 5 inches (127mm) O.D. on a 1 inch (25.4mm) core

Pro+ Models: 7.2 inches (182.9mm) O.D. on 3 inch (76.2mm), 1.5

inch (38.1mm), or 1 inch (25.4mm) cores

Ribbon Width Range

½” Core Ribbons

Ribbon Core Width: 4.3 inches (110mm)

Ribbon Width: 1.0 - 4.3 inches (25 - 110mm); Centered on core

1” Core Ribbons (with Ribbon Core Adapters, see section 2.4.1.)

Ribbon Core Width: 1.0 - 4.3 inches (25 - 110mm); Centered on

Ribbon Core Adapters

Ribbon Width: 1.0 - 4.3 inches (25 - 110mm); Centered on core

Ribbon Roll Capacity

0.5” (13mm) core with 361’ (110m) long ribbon or 1" (25mm) core

with 984' (300m) long ribbon


Communications

Interface Ports (standard)

USB, RS-232 (DB-9), IEEE 1284 Type C compliant mini-Centronics

parallel, and 10/100 Wired LAN

Baud Speed

600 to 38,400 bits per second (BPS)

Handshaking

Xon/Xoff, CTS, DTR

Parity

Even, Odd, or None

Stop Bits

1 or 2

Data Bits

7 or 8


Fonts

9 Bit Mapped Fonts rotated 0, 90, 180, and 270 degrees.


Embedded Bar Codes

32 embedded barcodes (see the Programmer’s Manual for a detailed listing).
