Chapter 3 – printer operation 29 – Datamax-O'Neil E-Class Mark III Operator’s Manual User Manual
Page 35
Chapter 3 – Printer Operation
29
Advanced Entry Calibration (continued)
Step
Action
Displayed Message
Comment
F
Using the
or
button, set the
Gain Number to 0.
Record the sensor reading as a
Label Value for Gain Number 00 in
a table (32 rows by four columns,
with headings similar to those
shown below.)
TRAN SENSOR GAIN
253
0
(0 - 31)
This is the Label Value for a gain
setting of 0.
Sample Calibration Table
Gain Number
Label Value
TOF Value
Difference Value
00 253
01
02
…
31
Step
Action
Displayed Message
Comment
G
Using the
button, increment the
Gain Number by one and then
Record the Label Value.
Repeat this process for each Gain
Number.
TRAN SENSOR GAIN
250
1
(0 - 31)
This is the Label Value for a gain
setting of 1.
Sample Calibration Table
Gain Number
Label Value
TOF Value
Difference Value
00 252
01 250
02 248
… …
31 09
