Chapter 3 – Printer Operation

31

Advanced Entry Calibration (continued)

Step

Action

Displayed Message

Comment

J

Using the

button, increment the

Gain Number by one. Record the

TOF Value. Repeat this process for

each Gain Number.

TRAN SENSOR GAIN

245

1

(0 - 31)

These are TOF Values, where

“245” represents the current

sensor reading.

Sample Calibration Table

Gain Number

Label Value

TOF Value

Difference Value

00 252 248
01 250 245
02 248 234

… … …

31 09 14

Step

Action

Displayed Message

Comment

K

In your sample calibration table,

where both the Label Value and

TOF Value are at least 20, subtract

the amounts and record the result

as a Difference Value (see below).

Identify the largest Difference

Value and the corresponding Gain

Number. This Gain Number will be

used to resample the media.

TRAN SENSOR GAIN

14

31

(0 - 31)

In the example below, Gain

Number 18 is chosen because;

both values are at least twenty

and it has the highest Difference

Value.

Sample Calibration Table

Gain Number

Label Value

TOF Value

Difference Value

00 252 248 4
01 250 245 5
02 248 234 14

… … … …

15 188 63 125
16 184 51 133
17 179 38 141
18

174

25

149

19 170 19 N/A

… … … …

31 132 14 N/A
