Chapter 3 – Printer Operation

33

Advanced Entry Calibration (continued)

Step

Action

Displayed Message

Comment

N

Press the

button to exit the

current menu level.


Using the

button, scroll to

PAPER SENSOR LEVEL (or if using

reflective media, REFL PAPER
LEVEL) and then press the

button.


Using the

or

button, set the

Paper value determined in Step M
and then press the

button.

PAPER SENSOR LEVEL

174

(0 - 255)

This is the Paper value.

O

Using the

button, scroll to GAP

SENSOR LEVEL (or, if using

reflective media, MARK SENSOR
LEVEL) and then press the

button.


Using the

or

button, Set the

Gap (or Mark) value determined in
Step M and then press the

button.

GAP SENSOR LEVEL

042

(0 - 255)

This is the Gap (or Mark) value.

P

Using the

button, scroll to

EMPTY SENSOR LEVEL and then
press the

button.

Set the Empty value determined in
Step M and then press the

button.

EMPTY SENSOR LEVEL

9

(0 - 255)

This is the Empty value.

Q

Press the

repeatedly

to exit

the menu, select YES at the SAVE

CHANGES prompt and then press
the

button.

Save Changes?

No

>Yes

Save Changes. The printer is

ready for use.

If the calibration attempt fails, try desensitizing the sensor as follows:

Go to MEDIA SETTINGS / SENSOR CALIBRATION / ADVANCED ENTRY / TRAN (or REFL) SENSOR GAIN

and lower the corresponding GAIN SETTING by one.

Exit the menu and save your changes. Test your media at the new setting. If necessary, repeat until a

usable Gain Setting is obtained.
