Chapter 2 – Printer Setup
11
2.3.5 Adjustable Media Core Hangers
(Pro+ models only)
The Adjustable Media Core Hangers allow for support of media rolls with 3”, 1.5”, or 1” cores.
To adjust:
1) Pull outward in on the Core Hanger and slide the Core Hanger up or down to the desired setting.
Be sure both core hangers are set to the same position.
312
Media Hanger
Core Hanger
3”, 1.5”, and 1” Core Positions
Not in use Position
(for fanfold or external supply)
