Control Access Display Table
Editable- True = Value is adjustable . False = Value is
‘read only’ .
Many of the Menus in the Control Access Display Table are
typical of each module, Menus for subsequent modules
are not listed . To preserve space in this document, these
single Menus are represented with a title of MOD X, and can
be viewed, Module by Module, in the BACview Interface
Device .
Multiple Accesses to Menu Tables
While navigating the BACview Interface Device, there are
multiple ways to access many Menus . The intent of the
Control Access Display Table is to provide concise direction
to access each Menu and Object in the BACview Interface
Device using a single method for each . While Menus are
included in multiple locations in the BACview Interface
Device, they will not be included in all the Menus herein .
However, every Menu is accessible using the Control Access
Display Table as a reference . This document locates these
Menus in an appropriate location based on the nature of
the object .
Use of this Table during Startup
It is of the utmost importance to review all the settings
in the FN2, FN6, FN7 and FN8 Menus while performing
start up to confirm proper configuration for the intended
application. This review must also confirm that all alarm
set points meet the required values for the system . Please
consider the type of equipment installed, heat transfer
medium used for each individual fluid loop, and safe
minimum flow rates for each fluid loop in the chiller system.
Please contact ClimaCool Corp Technical Service for any
questions related to the Control Access Display Table and
any content contained within .
Page 1 of 15 10/9/2013
Product Line: UGW
Software Version: UGW-H.08B.13 Chiller Type: COOLING 4 PIPE
STANDBY
Screen Display
Content BACnet Object Default Min. Value Max. Value Editable
ClimaCool Corp. CoolLogic
Date:
Time:
CHWS Temp:
EVAP OUT TMP chws_temp_1 50.1 °F FALSE
F CWR Temp: (F) COND OUT TMP cwr_temp_1 83.3 °F FALSE
press any key to continue
HOME
Screen Display
Content BACnet Object Default Min. Value Max. Value Editable
Chill Water In: (F) CHWR In Temp Status chwr_stat_1 54.4 FALSE
/Cool Spt: (F) Active CHW Setpoint chw_stp_stat_1 45.0 °F FALSE
Chill WaterOut: (F) CHWS Out Temp Status chws_stat_1 50.2 FALSE
/ Tot Stg Want: Num of Comp Requested comp_req_1 2.0 FALSE
Cond Water In : (F) CWS In Temp Status cws_stat_1 67.3 °F FALSE
/ Tot Stg On: Num of Comp ON comp_on_1 2.0 FALSE
Cond Water Out: (F)
/ Mode :
Mode mode_1
CLG
Cooling,
Heating
FALSE
Chil Water Flow :
/Heat Spt: (F)
Evap Flow SW evap_flow_1 On No, Yes FALSE
Cond Water Flo: Cond Flow SW cond_flow_1 On No, Yes FALSE
/UnitMode: Unit Mode unit_mode_1
Normal Run
Schedule, No
Flo/Phas,
CHWR High,
CWS Low, Sens
Error, No
ModAvail,
Module Down,
Compr Down,
NonCrit Alm,
Normal Run
FALSE
LINK(S): STATUS, SYSTEM SETUP, SERVICE MENU SETUP, ALARM
STATUS
Screen Display
Content BACnet Object Default Min. Value Max. Value Editable
CoolLogic Chiller Status Menu
LINK(S): ALL MODULE COMP UNLOAD STATUS,MODULE SIZE STATUS, CHILLER OPER STATUS,EVAP STATUS, COND STATUS,MOT VLV OPEN/CLOSE STATUS MENU,
MOD1 COMP1 DATA,MOD2 COMP1 DATA,MOD3 COMP1 DATA,MOD4 COMP1 DATA,MOD5 COMP1 DATA,MOD6 COMP1 DATA,ALL COMPR RUNTIME STATUS,
ALL COMPR CYCLES STATUS,ALL COMPR SS STATUS, ALL COMPR AMPERAGE STATUS,PREV, CLOCKSET, HOME, ALARM
MODULE SIZE STATUS
Screen Display
Content BACnet Object Default Min. Value Max. Value Editable
Module Size Status Only Legend
Mod1 Size:[
]/ 1= Not Used /4=80Ton Mod
Mod 1 Size m1_size_st_1 4.0 1 4 FALSE
Mod2 Size:[
]/NOTE:DO NOT SELECT 2 OR 3
Mod 2 Size m2_size_st_1 4.0 1 4 FALSE
Mod3 Size:[
]
Mod 3 Size m3_size_st_1 4.0 1 4 FALSE
Mod4 Size:[
]
Mod 4 Size m4_size_st_1 4.0 1 4 FALSE
Mod5 Size:[
]
Mod 5 Size m5_size_st_1 1.0 1 4 FALSE
Mod6 Size:[
]
Mod 6 Size m6_size_st_1 1.0 1 4 FALSE
LINK(S): PREV, ALARM, SYSTEM SETUP, CLOCKSET
CHILLER OPER STATUS
Screen Display
Content BACnet Object Default Min. Value Max. Value Editable
CoolLogic Operating & Loading Status
PID1 Count:
Stage 1 Cooling PID stg1_clg_pid_1 106.719604 FALSE
/Chil WaterOut: (F) CHWS Out Temp Status chws_stat_1 50.2 FALSE
Mod1 VFD Volt: M1 VFD Screw Input m1vfd_screw_input_1 7.53594 V 0 999 FALSE
/Mod2 VFD Volt: M2 VFD Screw Input m2vfd_screw_input_1 4.4 V 0 999 FALSE
Mod3 VFD Volt: M3 VFD Screw Input m3vfd_screw_input_1 0.0 °F 0 999 FALSE
/Mod4 VFD Volt: M4 VFD Screw Input m4vfd_screw_input_1 0.0 °F 0 999 FALSE
HPID1 Count: Stage 1 Heating PID stg1_htg_pid_1 0.0 FALSE
/Cond WaterOut: (F) CWR Out Status cwr_stat_1 83.3 FALSE
Cool Spt: Active CHW Setpoint chw_stp_stat_1 45.0 °F FALSE
F / Heat Spt: (F) Active Htg Setpoint cw_stp_stat_1 125.0 °F FALSE
Unit Stat: Unit Status unit_status_1
On
Unit OFF, Unit
ON
FALSE
LOCAL ACCESS DISPLAY TABLE
Control Access Display Table
