Tool ConfiguraTions
Climax Portable Machining & Welding Systems Web site: climaxportable.com
Worldwide Phone:
1.503.538.2185 N. America Toll-Free: 1.800.333.8311 Fax: 1.503.538.7600 E-mail: [email protected]
page 5
OPTION 3: To configure your FF8200 for Milling, or Milling with Single Pointing
To configure your machine, please follow these steps.
1 Select a Base Package
2 Select a Feed Assembly
3 Select a Drive Motor Assy
4 Select a Hydraulic Motor
5 Select an Optional Grinder
6 Select a Hydraulic Power Unit
7 Select a Turning Arm Assembly
8 Select a Counterweight Assy
9 Select a Milling Head
10 Select a Tooling
12 Select a Chuck Assembly
13 Select a Shipping Container
1 Base Package
Rotary table, tool kit, drag brake assemblies,. 62670
operator's manual.
2 Feed Assembly
Pneumatic Feed Assembly w/ Remote Air Control 58671
3 Drive Motor Assembly
Pneumatic Motor and Drive Assembly 62591
(Pneumatic drive system includes: Pneumatic
motor w/fittings and mount, gearbox, rotary
union, hoses, feed trip valve, cam, & pneumatic
conditioning unit with low pressure drop out.)
Hydraulic Drive Assy w/Gearbox & Feed 62594
Conditioning Unit - DOES NOT INCLUDE
MOTOR (Hydraulic drive system includes:
Hyd motor mount, gearbox, hoses, fittings,
rotary union, feed trip valve, cam, and
feed pneumatic conditioning unit.)
4 Hydraulic Motor for Rotary Table Drive
(If Hydraulic drive is selected in step 3)
Rated at 10 gpm, 1200 PSI
Fast RPM = Single Point Machining / Slow RPM = Milling
Hydraulic Motor, 4.9 cu in (80.3 cu cm), 69213
16 - 56 RPM / 0.1 - 0.35 RPM
Hydraulic Motor, 8.0 cu in (131.1 cu cm), 69214
8 - 32 RPM / 0.05 - 0.20 RPM
Hydraulic Motor, 14.9 cu in (244.2 cu cm), 69216
3.6 - 18 RPM / 0.02 - 0.11 RPM
Hydraulic Motor, 18.7 cu in (306.4 cu cm), 69217
2.8 - 14 RPM / 0.018 - 0.09 RPM
Hydraulic Motor, 24.0 cu in (393.3 cu cm), 69218
2.2 - 11 RPM / 0.014 - 0.07 RPM
Hydraulic Motor, 29.8 cu in (488.3 cu cm), 69219
1.8 - 9 RPM / 0.012 - 0.06 RPM
* Multiple units may be ordered.
5 Optional Grinder Attachment
Grinding Attachment for Pneumatic Table Drive Motor 62537
Grinding Attachment for Hydraulic Table Drive Motor 62570
Grinder Tooling
Grinding Wheel 1.5 in (38.1 mm), CBN 130 Grit 62633
Grinding Wheel 2.25 in (57.2 mm), CBN 130 Grit 62634
6 Hydraulic Power Unit
Single Pump (for pneumatic table rotation):
HPU 230V, 25HP Single pump with Air 62774
HPU 380V, 25HP Single pump with Air 62775
HPU 415V, 25HP Single pump with Air 62776
HPU 460V, 25HP Single pump with Air 62777
HPU 575V, 25HP Single pump with Air 62778
Dual Pump (with air) for hydraulic
table rotation,hydraulic milling head,
and air for grinding attachment:
HPU 230V, 25HP Dual Pump with Air 62779
HPU 380V, 25HP Dual Pump with Air 62780
HPU 415V, 25HP Dual Pump with Air 62781
HPU 460V, 25HP Dual Pump with Air 62782
HPU 575V, 25HP Dual Pump with Air 62783
Dual Pump (for hydraulic table rotation
and hydraulic milling head):
HPU 230V, 25HP Dual Pump 62784
HPU 380V, 25HP Dual Pump 62785
HPU 415V, 25HP Dual Pump 62786
HPU 460V, 25HP Dual Pump 62787
HPU 575V, 25HP Dual Pump 62788
Pendant Cable & Hose, Single Pump
0.75 in (19.1 mm) Hose and Pendant Cable Assy, 62803
20 ft (6.1 m)
0.75 in (19.1 mm) Hose and Pendant Cable Assy, 62804
30 ft (9.1 m)
0.75 in (19.1 mm) Hose and Pendant Cable Assy, 62805
50 ft (15.2 m)
0.75 in (19.1 mm) Hose and Pendant Cable Assy, 62806
100 ft (30.75 m)
Pendant Cable & Hose, Dual Pump
0.5 in (12.7 mm) & 0.75 in (19.1 mm) Dual Hose 62807
& Pendant Cable Assy, 20 ft (6.1 m)
0.5 in (12.7 mm) & 0.75 in (19.1 mm) Dual Hose 62808
& Pendant Cable Assy, 30 ft (9.1 m)
0.5 in (12.7 mm) & 0.75 in (19.1 mm) Dual Hose 62809
& Pendant Cable Assy, 50 ft (15.2 m)
0.5 in (12.7 mm) & 0.75 in (19.1 mm) Dual Hose 62810
& Pendant Cable Assy,100 ft (30.5 m)
7 Turning Arm Assembly
Milling Arm Assembly with Single Point Tool Head 62578
8 Counterweight Assembly
Counterweight Milling Arm Assembly 62527
9 Milling Head
Milling Head Assembly Inch #50 Taper NMTB 62282
Milling Head Assembly Inch #50 Taper CATV 62734
Milling Head Assembly Metric #50 Taper NMTB 62644
Milling Head Assembly Metric #50 Taper CATV 62735
10 Tooling (for inch milling head assembly only)
#50, NBTB 4 in (101.6 mm) Face Mill w/ Inserts 47383
#50, NBTB 5 in (127.0 mm) Face Mill w/ Inserts 47384
#50, NBTB 6 in (152.4 mm) Face Mill w/ Inserts 47385
#50, NBTB 8 in (203.2 mm) Face Mill w/ Inserts 47386
#50, NBTB 10 in (254.0 mm) Face Mill w/ Inserts 56175
Carbide Inserts 47229
11 Milling Head Swivel Assembly
Milling Head Swivel Plate Assembly 63250
12 Hydraulic Motor for Milling Head
Hydraulic Motor Assembly 8.0 cu in (131.1 cu cm) 53459
Hydraulic Motor Assembly 9.6 cu in (157.3 cu cm) 53458
Hydraulic Motor Assembly 11.9 cu in (195.0 cu cm) 46950
Hydraulic Motor Assembly 14.9 cu in (244.2 cu cm) 46375
Hydraulic Motor Assembly 18.7 cu in (306.4 cu cm) 46549
Hydraulic Motor Assembly 24.0 cu in (393.3 cu cm) 46550
13 Chuck Assembly
ID Chuck Assembly 57881
OD Chuck Assembly for Milling Arm 62669
ID/OD Chuck Assembly for Milling Arm 62677
14 Shipping Container
Wooden Crate for ID Mount Machine 58421
Metal Container for ID Mount Machine 59936
Wooden Crate Set for ID/OD Mount Machine 62679
Metal Container Set for ID/OD Mount Machine 61724
