FF5000 Flange Facer
light, Portable, and Powerful -
Designed to get the job done FaST!
The FF5000 is a versatile flange facing
machine that allows you to face, bevel, and
turn pipe, valve, and pump flanges with
ease. The two-piece mounting
system makes setup and alignment of this
machine quick and easy. It allows one
operator to easily set up the
machine and begin machining in just a few
minutes.
Quick and Easy Setup & Removal
• Separate mounting chuck.
• All centering and leveling is done on the
chuck.
• Loosen one bolt and machine can be
removed from the chuck without
disturbing alignment or calibration.
Lightweight
• Body of machine weighs only
60 lbs (27.2 kg).
• Smallest mounting chuck weighs about 5
lbs (2.2 kg).
Low Profile
• Right angle motor mount.
• Machine extends only 7.6 inches (193.0
mm) above flange.
Safe and Quiet Operation
• Stationary feed rate selector.
• Machine is controlled without
touching any moving parts.
• Exhaust air is routed through body of
machine for increased muffling.
Simplified Operation
• Single selector switch for bidirectional
radial feed or vertical downfeed.
• One wrench size for clamping jaws and
body draw bolt.
Cuts Chamfers and Grooves
• Compound tool head and downfeed for
cutting angles and grooves.
