Tool ConfiguraTions

Climax Portable Machining & Welding Systems Web site: climaxportable.com
Worldwide Phone:

1.503.538.2185 N. America Toll-Free: 1.800.333.8311 Fax: 1.503.538.7600 E-mail: [email protected]

page 4

OPTION 2:

To configure your FF8200 for Milling Only

To configure your machine, please follow these steps.

Select a Base Package

Select a Drive Motor Assembly

Select a Hydraulic Motor

Select an Optional Grinder Attachment

Select a Hydraulic Power Unit

Select a Turning Arm Assembly

Select a Counterweight Assembly

Select a Milling Head

Select a Hydraulic Motor

10 Select Tooling

11 Select a Chuck Assembly

12 Select a Shipping Container

1 Base Package

Rotary table, tool kit, drag brake assemblies,.

62673

operator's manual.

2 Drive Motor Assembly

Pneumatic Motor and Drive Assembly

62571

(Pneumatic drive system includes: Pneumatic

motor w/fittings and mount, gearbox, rotary

union, hoses, feed trip valve, and pneumatic

conditioning unit with low pressure drop out.)

Hydraulic Drive Assy w/Gearbox - DOES NOT

62585

INCLUDE MOTOR OR PNEUMATIC SYSTEM

(Hydraulic drive system includes: Hyd motor

mount, gearbox, hoses, fittings, and rotary union.)

3 Hydraulic Motor for Rotary Table Drive

(If Hydraulic drive is selected in step 2)

Rated at 10 gpm, 1200 PSI

Hydraulic Motor, 4.9 cu in (80.3 cu cm),

69213

0.1 - 0.35 RPM

Hydraulic Motor, 8.0 cu in (131.1 cu cm),

69214

0.05 - 0.20 RPM

Hydraulic Motor, 14.9 cu in (244.2 cu cm),

69216

0.02 - 0.11 RPM

Hydraulic Motor, 29.8 cu in (488.3 cu cm),

69219

0.012 - 0.06 RPM

* Multiple units may be ordered.

4 Optional Grinder Attachment

Grinding Attachment for Pneumatic Table Drive Motor

62948

(tool head included)

Grinding Attachment for Hydraulic Table Drive Motor

62947

(tool head included)

Grinder Tooling

Grinding Wheel 1.5 in (38.1 mm), CBN 130 Grit

62633

Grinding Wheel 2.25 in (57.2 mm), CBN 130 Grit

62634

5 Hydraulic Power Unit

Single Pump (for pneumatic table rotation):

HPU 230V, 25HP Single pump with Air

62774

HPU 380V, 25HP Single pump with Air

62775

HPU 415V, 25HP Single pump with Air

62776

HPU 460V, 25HP Single pump with Air

62777

HPU 575V, 25HP Single pump with Air

62778

Dual Pump (with air) for hydraulic

table rotation and hydraulic milling head,

and air for grinding attachment:

HPU 230V, 25HP Dual Pump with Air

62779

HPU 380V, 25HP Dual Pump with Air

62780

HPU 415V, 25HP Dual Pump with Air

62781

HPU 460V, 25HP Dual Pump with Air

62782

HPU 575V, 25HP Dual Pump with Air

62783

Dual Pump (for hydraulic table rotation and

hydraulic milling head)

HPU 230V, 25HP Dual Pump

62784

HPU 380V, 25HP Dual Pump

62785

HPU 415V, 25HP Dual Pump

62786

HPU 460V, 25HP Dual Pump

62787

HPU 575V, 25HP Dual Pump

62788

Pendant Cable & Hose, Single Pump

0.75 in (19.1 mm) Hose and Pendant Cable Assy,

62803

20 ft (6.1 m)

0.75 in (19.1 mm) Hose and Pendant Cable Assy,

62804

30 ft (9.1 m)

0.75 in (19.1 mm) Hose and Pendant Cable Assy,

62805

50 ft (15.2 m)

0.75 in (19.1 mm) Hose and Pendant Cable Assy

62806

100 ft (30.75 m)

Pendant Cable & Hose, Dual Pump

0.5 in (12.7 mm) & 0.75 in (19.1 mm) Dual Hose

62807

& Pendant Cable Assy, 20 ft (6.1 m)

0.5 in (12.7 mm) & 0.75 in (19.1 mm) Dual Hose

62808

& Pendant Cable Assy, 30 ft (9.1 m)

0.5 in (12.7 mm) & 0.75 in (19.1 mm) Dual Hose

62809

& Pendant Cable Assy, 50 ft (15.2 m)

0.5 in (12.7 mm) & 0.75 in (19.1 mm) Dual Hose

62810

& Pendant Cable Assy,100 ft (30.5 m)

6 Turning Arm Assembly

Milling Arm Assembly (does not include tool head)

72698

7 Counterweight Assembly

Counterweight Milling Arm Assembly

62415

8 Milling Head

Milling Head Assembly Inch #50 Taper NMTB

62282

Milling Head Assembly Inch #50 Taper CATV

62734

Milling Head Assembly Metric #50 Taper NMTB

62644

Milling Head Assembly Metric #50 Taper CATV

62735

9 Tooling (for inch milling head assembly only)

#50, NBTB 4 in (101.6 mm) Face Mill w/ Inserts

47383

#50, NBTB 5 in (127.0 mm) Face Mill w/ Inserts

47384

#50, NBTB 6 in (152.4 mm) Face Mill w/ Inserts

47385

#50, NBTB 8 in (203.2 mm) Face Mill w/ Inserts

47386

#50, NBTB 10 in (254.0 mm) Face Mill w/ Inserts

56175

Carbide Inserts

47229

10 Milling Head Swivel Assembly

Milling Head Swivel Plate Assembly

63250

11 Hydraulic Motor for Milling Head

Hydraulic Motor Assembly 8.0 cu in (131.1 cu cm)

53459

Hydraulic Motor Assembly 9.6 cu in (157.3 cu cm)

53458

Hydraulic Motor Assembly 11.9 cu in (195.0 cu cm)

46950

Hydraulic Motor Assembly 14.9 cu in (244.2 cu cm)

46375

Hydraulic Motor Assembly 18.7 cu in (306.4 cu cm)

46549

Hydraulic Motor Assembly 24.0 cu in (393.3 cu cm)

46550

12 Chuck Assembly

ID Chuck Assembly

57881

OD Chuck Assembly for Turning with Milling Arm

62666

ID/OD Chuck Assembly for Turning with Milling Arm

62674

13 Shipping Container

Wooden Crate for ID Mount Machine

58421

Metal Container for ID Mount Machine

59936

Wooden Crate Set for ID/OD Mount Machine

62679

Metal Container Set for ID/OD Mount Machine

61724
