Page 6

6 10/98
PM Operational Dimensions
Model
Dim. A
Dim. B
No. of
Dim. C
Long. Travel
Bed Length
Mtg Holes Hole Spacing
PM2000
20.0 (508.0)
29.0 (736.6)
6
10. (2)
PM3000
49.0 (1244.6)
58.0 (1473.2)
12
10.0 (254.0)
PM4000
78.0 (1981.2)
87.0 (2209.8)
18.0 (25)
PM Series Portable Mill
8.69 (220.73)
10.18 (258.57)
.56 (14.22)
dia.
13.6 (345.4) min
16.6 (421.6) max
4.0 (101.6)
1.5 (38.1)
1.25
(31.75)
4.0
(114.3)
C
6.7
(170.2)
.6 (15.2)
2.18 (55.37)
3.55
(90.17)
8.0 (203.2)
travel
13.00 (330.2) min
21.00 (533.4) max
4.5 (165.1)
11.3 (287.0)
3.0 (76.2)
vert. travel
.85 (21.59)
A
B
PM-B Series Portable Mill
11.3
(287.0)
10.80 (274.32) min
17.20 (432.82) max
6.04
(153.42)
2.13
(54.10)
6.7
(170.2)
4.5
(165.1)
2.30 (58.42)
A
B
C
5.0 (127.0)
4.0
(114.3)
1.25
(31.75)
11.0
(279.4)
8.69 (220.73)
10.18 (258.57)
.56 (14.22) dia.
1.5 (38.1)
2.13 (54.1)
Inches (mm)
Specifications subject to
change without notice.
Please refer to the
Technical Information
page for further details.
.50 (12.7)
6.4 (162.5)
tool slide
travel
Spindle
C L
Spindle
C L
