60 Importing a DBC file
Display Creator User Manual – MoTeC Ⓒ 2014 Published 1 July 2014 www.motec.com
Updating a DBC File Import
Once a DBC file has been imported it is possible to do a compare between an updated Dash Manager
configuration and the Display Creator configuration.
The icons used to indicate differences are shown in the following table.
Icon Meaning
The message is not the same, it contains any number of differences to signals.
The signal exists in Display Creator but has been removed from the Dash Manager configuration. On accepting the update,
any such signals will be removed from the Display Creator configuration.
The signal does not exist in Display Creator and can be added.
The Dash Manager and Display Creator configurations are the same.
In the example below, the following scenario takes place:
