48 PN: 11410-00611 Rev. A MS4640B Series TDS
Ordering Information VectorStar™ MS4640B Series
Ordering Information
Instrument Models The VectorStar MS4640B Series VNAs are available in four models to meet different frequency range
requirements. Refer to “Standard Capabilities” on page 2-27 for extended operational frequency ranges.
MS4642B Vector Network Analyzer 10 MHz to 20 GHz
MS4644B Vector Network Analyzer 10 MHz to 40 GHz
MS4645B Vector Network Analyzer 10 MHz to 50 GHz
MS4647B Vector Network Analyzer 10 MHz to 70 GHz
Included Accessories Each VNA comes with a set of included accessories.
User Documentation CD The user documentation CD includes PDF files for the VectorStar Operation Manual, User Interface Reference
Manual, Programming Manual, Programming Manual Supplement, Calibration and Measurement Guide, Technical
Data Sheet and Configuration Guide, and Maintenance Manual.
Online Help The instrument is equipped with context-sensitive help built from the first five documents above.
Peripherals Optical USB Mouse
Power Power Cord
Main VNA Options
MS4640B-001 Rack Mount, adds handles and removes feet for shelf-mounting into a 19” universal rack
MS4640B-002 Time Domain
MS4640B-004 Additional Serial-ATA (SATA) Solid State Drive (SSD) with OS and VectorStar Application Software
MS4640B-007 Receiver Offset
MS464xB-031 Dual Source Architecture
MS4640B-035 IF Digitizer
MS4640B-041 Noise Figure, requires Option 051, 061, or 062
MS4640B-042 PulseView™, requires Option 035
MS4640B-043 DifferentialView™
MS464xB-051 Direct Access Loops, see description below
MS464xB-061/062 Active Measurement Suite options, see description below
MS4640B-070 70 kHz Low-End Frequency Extension
Direct Access Loop Options Note: Direct access loops are not available for VNAs equipped with Options 061 or 062, which include loops.
MS4642B-051 Direct Access Loops for MS4642B, not available with Options 061 or 062
MS4644B-051 Direct Access Loops for MS4644B, not available with Options 061 or 062
MS4645B-051 Direct Access Loops for MS4645B, not available with Options 061 or 062
MS4647B-051 Direct Access Loops for MS4647B, not available with Options 061 or 062
Active Measurement Suite Options
MS4642B-061 Active Measurements Suite, For MS4642B, with 2 Step Attenuators
MS4642B-062 Active Measurements Suite, For MS4642B, with 4 Step Attenuators
MS4644B-061 Active Measurements Suite, For MS4644B, with 2 Step Attenuators
MS4644B-062 Active Measurements Suite, For MS4644B, with 4 Step Attenuators
MS4645B-061 Active Measurements Suite, For MS4645B, with 2 Step Attenuators
MS4645B-062 Active Measurements Suite, For MS4645B, with 4 Step Attenuators
MS4647B-061 Active Measurements Suite, For MS4647B, with 2 Step Attenuators
MS4647B-062 Active Measurements Suite, For MS4647B, with 4 Step Attenuators
Pulse Modulator Test Sets
SM6628 Pulse Modulator Test Set, 70 kHz to 40 GHz, for source modulation with an MS4642B or MS4644B
SM6629 Pulse Modulator Test Set, 70 kHz to 40 GHz, for source and receiver modulation with an MS4642B or MS4644B
SM6630 Pulse Modulator Test Set, 70 kHz to 70 GHz, for source modulation with an MS4645B or MS4647B
SM6631 Pulse Modulator Test Set, 70 kHz to 70 GHz, for source and receiver modulation with an MS4645B or MS4647B
Multiport VNA Options The multiport VNA option provides four test ports for all VectorStar MS4640B Series VNAs with the MN4690B
Series Multiport Test Sets. The option provides the Test Set, necessary cabling, and installation documentation.
The Test Set frequency range is limited to that of the attached VNA.
MN4694B 70 kHz to 40 GHz, Use the MN4694B Test Set with MS4642B and MS4644B VNAs
MN4697B 70 kHz to 70 GHz, Use the MN4697B Test Set with MS4645B and MS4647B VNAs
Documentation For detailed MN4690B specifications, refer to the VectorStar MN4690B Series Multiport VNA Technical Data Sheet
– 11410-00528
