46 016-030-B0-005, Rev. C
5.0 Specifi cations, continued
5.2 APX Specifi cations
Model APX 6008 E APX 6014 E APX 6008 P APX 6014 P APX 4808 E APX 9015
Input Voltage
(Nom) 120
230 120
230
220 220 230 240
Input Freq (Hz) 60
50 60
50
60 60 50 60
Input Current
(A) (Max) 3.5
1.9 6.2
3.2
2.3 3.4 2 11.2
Output Voltage
(VAC) (Nom) 60
60 60
60
60 60 40 90/75/60
Output Current
(A) (Max) 8
8 14
14
8 14 8 15
Output Power (VA) 480
480 840
840
480 840 384 1350
Output Current Limit 150% of Max Output Rating
Regulation +/- 5%
Input Protection
(Circuit Breaker)
8 Amp 12 Amp 8 Amp 12 Amp 8 Amp 20 Amp
Output Protection
(Fuse)
10 Amp 15 Amp 10 Amp 15 Amp 10 Amp 20 Amp
Effi ciency 90% or better with nominal input voltage, frequency, full load 25c ambient
Finish Gray, ASA Polyester Powder Coat
Operating Temp
Range
-40° F to +130° F (-40° C to +55° C)
Dimensions HxWxD
Pole mount
Shelf mount
w/MTA
Pedestal mount (PM)
Universal Bracket
Rack mount
Wall mount Bracket
w/PM unit installed
11.75" x 7.5" x 10.5" (298mm x 190mm x 267mm)
2.3" x 6.7" x 11.6" (60mm x 170mm x 295mm)
7.9" x 6.7" x 11.6" (200mm x 170mm x 295mm)
27.3" x 8.5" x 8.5" (693mm x 216mm x 216mm)
14.0" x 7.1" x 7.35" (356mm x 180mm x 187mm)
7.0" x 19" x 6.5" (178mm x 483mm x 165mm)
7.1" x 2.7" x 2.0" (180mm x 69mm x 51mm)
11.5" x 7.85" x 10.75" (298mm x 200mm x 267mm)
15" x 10.5" x 7.5"
(381mm x 267mm x
190mm)
Weight
(lbs/kg)
21/14.5 30/13.6 24/10.9 34/15.4 22/10 48/21.7
Table 5-1, APX Series Specifi cations
