Alpha Technologies APX Series - Manual (Page 28)

28 016-030-B0-005, Rev. C
Fig. 2-16, Service Entrance / Meter Connections, 120VAC
Fig. 2-17, Service Entrance / Meter Connections, 240VAC
NOTE:
Service electric ground must be unbroken to service disconnect. All local utility and building codes
apply.
2.0 Installation, continued
2.7 External Service Disconnect, continued
To Utility
Neutral (WHITE)
Neutral Bus L1 (BLACK)
L2 (RED)
To Enclosure Receptacle Breaker
Ground (GREEN)
#8AWG (minimum)
Copper Ground Wire
Ground Clamp
4
1
2
6
8
9
10
3
7
5
1
2
3
4
5
6
7
8
9
10
