1.0 Introduction,

continued

1.2 Standard

Confi gurations, continued

Enclosure

Cover

Baseplate

Assembly

Main Transformer Assembly

(MTA)

Fig. 1-2, Pole Mount Enclosure

Holes for

Padlock

Fig. 1-3, APX Main Transformer Assembly
