NAME DATE
APPROVED
CHECKED
DRAWN
DESIGN 2010/01
2010/01
2010/01
2010/01
JK
KL
RP
JK
SCALE:
THESE DESIGNS AND SPECIFICATIONS ARE CONFIDENTIAL, REMAIN
THE PROPERTY OF ALPHA TECHNOLOGIES LTD., AND SHALL NOT
BE COPIED OR USED WITHOUT ITS WRITTEN CONSENT.
TYPE
0.5
D2
1
0.5
0.05
0.002]
[ 0.040]
[ 0.020]
[
UNITS: mm [in]
X [X.X]
X.X [X.XX]
X.XX [X.XXX]
ANGULAR:
OF
1/20/2010 ALPHA TECHNOLOGIES
TITLE:
ISSUE
DATE
SIZE
B
DWG NO.
KIT, PLINTH,
W/ MOUNTING HARDWARE,
4"H X 30" W X 30"D
747-592-F0
SHEET
NTS
REV
A
1 1
ITEM
QTY
REVISIONS
DESCRIPTION LTR APPD DATE DWN CHKD
ITEM
NO.
PART
NUMBER
DESCRIPTION QTY.
1 615-311-R8
ASSY, PLINTH, 30"X30",
STL, EXT GRAY
1
5 634-092-10
Nut,1/2"-13,Hex,3/4"
AF,7/16" Thk,SSt
4
9 633-159-10
WASHER, LOCK, HELICAL
SPRING, 1/2" BOLT, SST
4
10 633-615-10
WASHER, FLAT, 1/2", 1.25"
OD, 0.084"THK, SST
8
14 631-170-10
SCREW, CAP, 1/2-13X2",
HEXHEAD, SST
4
20 570-026-10
PLUG, PLINTH END, 6"X4",
PLASTIC
4
1
1
1
4 PL
1
10
4 PL
1
14 10
1
9
20
1
5
1
4 PL
©
