THESE DESIGNS AND SPECIFICATIONS ARE CONFIDENTIAL, REMAIN
THE PROPERTY OF ARGUS TECHNOLOGIES LTD., AND SHALL NOT
BE COPIED OR USED WITHOUT ITS WRITTEN CONSENT.
TYPE
D2
1
0.5
0.05
0.5
[ 0.040]
[ 0.020]
[ 0.002]
UNITS: mm [in]
X [X.X]
X.X [X.XX]
X.XX [X.XXX]
ANGULAR: SCALE:
OF
2009 ARGUS TECHNOLOGIES
TITLE:
ISSUE
DATE
SIZE
B
DWG NO.
CUSTOMER CONNECTION,
KIT, INTRFC, w/ CBL SET,
BATT TO BATT, Te4x
747-603-08
SHEET
NTS
REV
P/A
7 7
AIR CONDITIONER AC POWER CONNECTION:
UTLIITY BOX
Te40 AIR CONDITIONER UTILITY BOX WIRING
CONNECT A SEPARATE POWER CABLE TO THE EXISTING AIR CONDITIONER
AC WIRING INSIDE THE UTILITY BOX AND ROUTE IT OUT THROUGH
THE ENCLOSURE(S) TO A SEPARATE AC POWER SUPPLY FEED.
NOTE:
THE AIR CONDITIONER UNIT MUST BE SUPPLIED FROM A SEPARATE
AC SOURCE PROTECTED BY A 15A 120VAC RATED 1 POLE CIRCUIT BREAKER
AHEAD OF IT.
THIS CONNECTION CAN ALSO BE MADE TO THE OPTIONAL EXTERNAL
AC LOADCENTER ON THE Te41 POWER ENCLOSURE IF INSTALLED.
Te40 AIR CONDITIONER AC POWER WIRING
