Alpha Technologies Ltd. 057-104-C0 Rev B WC
Burnaby, British Columbia. Telephone: 604 436 5900 Fax: 604 436 1233. Page 7 of 27
2.3 Heating, ventilating, and air conditioning (HVAC)
An air conditioner/heater package is mounted on the front door of the enclosure. It provides cooling/heating for
the batteries and customer equipment. Refer to the HVAC manual supplied with the unit for operation and
maintenance details.
Three-point door latch
Figure 4 – Miscellaneous enclosure features
HVAC exhaust
HVAC controls
HVAC intake
