MLC 52 IR VC and MLC 52 RS VC Cutout Template for Mounting Directly to
a Wall or Furniture
To mount the MLC 52 RS VC or MLC 52 IR VC directly to a wall or furniture, use the
dimensions shown below to cut the hole in the mounting surface.
MLC 52 VC
(Front View)
Cut-Out Template for
4.60" (11.68 cm)
To install an MLC 52 VC
directly into
furniture or a wall,
cut along this line.
Top Panel
2.91"
(7.40 cm)
3.50"
(8.90 cm)
SURFACE CUT-OUT AREA
FOR FURNITURE MOUNT
Location of MLC 52
4.50"
(11.43 cm)
Figure 57.
Cutout Template for Mounting an MLC 52 IR VC or MLC 52 RS VC
Directly to a Wall or Furniture
MLC 52 MediaLink Controllers • Reference Information
67
