Command and Response Table for SIS Commands
Command
ASCII Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Information Requests
Query firmware version
Q
X!]
Display firmware version
X!
to
two decimal places (n.nn).
Example:
Q
1.00
]
View controller part number
N
60-74n-nn
]
Show the MLC 52 part number:
MLC 52 IR = 60-744-02
MLC 52 RS = 60-744-12
MLC 52 IR VC = 60-745-02
MLC 52 RS VC = 60-745-12
MLC 52 RS MK = 60-744-23
MLC 52 RS EU = 60-744-34
MLC 52 RS MK VC =
60-745-23
MLC 52 RS EU VC =
60-745-34
Query model name
I
MLC•52•IR
]
or
MLC•52•RS
]
or
MLC•52•IR•VC
]
or
MLC•52•RS•VC
]
or
MLC•52•RS•EU
]
or
MLC•52•RS•MK
]
or
MLC•52•RS•EU•VC
]
or
MLC•52•RS•MK•VC
]
Show the name of the MLC 52
model.
Display Power Status
Turn display power on
1P
Pwr1
]
Turn display power off
0P
Pwr0
]
View display power status
P
Pwr
X@]
For
X@
:
0 = on
1 = off
2 = cooling down
3 = warming up
Example:
P
Pwr2
]
The projector or display is
cooling down.
Front Panel Lockout (Executive Mode)
Off
0X
Exe0
]
Unlock front panel buttons.
On
1X
Exe1
]
Lock all front panel buttons.
View
X
X#]
View front panel lockout status
X#
. For
X#
:
0 = unlocked; 1 = locked.
Reset
Reset unit to factory defaults
E
ZXXX
}
ZapX
]
Reset all MLC 52 buttons and
switches to the factory default
and erase any codes added by
the user.
