Symbol definitions – Extron Electronics MLC 52 Series User Guide User Manual
Page 64
Symbol Definitions
] = CR/LF (carriage return/line feed) (hex
0D
0A
)
} = Soft carriage return (no line feed) (hex
0D
; web | )
•
= Space
E
= Escape key (hex
1B
; web
W
)
X! = Firmware version number (n.nn format)
X@ = Display power status (
0
through
3
)
0
= power off
1
= power on
2
= cooling down
3
= warming up
X# = Front panel lock status
0
= unlocked
1
= locked
NOTE: Unless otherwise indicated, commands are not case-sensitive.
MLC 52 MediaLink Controllers • Serial Communication
58
