Command
ASCII Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Reset/Erase
Configuration reset
E
ZXXX
}
ZapXXX
]
Reset the MLC configuration to
the factory default.
Information Requests
Query firmware version
Q
X*
]
Display firmware version
X*
to
two decimal places.
Example
Q
1.00
]
The current firmware version is
1.00.
Query firmware compatibility
version
**Q
X2%
]
Display firmware compatibility
version
X2%
.
Query device configuration
compatibility version
E
DIMQ
}
X2^
]
View the device configuration
compatibility version number
X2^
.
NOTE: Compatibility version numbers are used to track and check for compatibility between the configuration
software, firmware, and device configuration versions on the MLC. The device and firmware
compatibility numbers (
X2%
and
X2^
) each consist of six digits. The first three digits are called “major
numbers,” and the three digits following the decimal point are “minor numbers.”
Whenever the major numbers match, they are considered to be compatible. The minor numbers are
used to track changes that have been made but do not affect compatibility. However, if the minor
numbers do not match, the version may not be backward compatible. (See “Updating Firmware” in the
MLC help file for more information on checking compatibility.)
Example
E
DIMQ
}
002.100
]
Display the current device
compatibility number 002.100.
Major number is 002; minor
number is 100.
Request controller part number
N
60-nnnn-nn
]
Show the MLC part number:
MLC 62 RS D = 60-1005-02
MLC 62 RS EU = 60-1005-35
MLC 62 RS MK = 60-1005-23
MLC 62 IR D = 60-1006-02
MLC 64 RS D = 60-1182-02
Query model name
I
MLC•62•RS•D
]
or
MLC•62•RS•EU
]
or
MLC•62•IR•D
]
or
MLC•64•RS•D
]
Show the name of the MLC
model.
