Page 76
Command
ASCII Command
(host to switcher)
Response
(switcher to host)
Additional
Description
Set Group Master Value
Set value (dB)
E
DX^*X*GRPM}
GrpmDX^*X*]
Set the value X* for
group number X^.
NOTE:
Reserved groups are: 1 = program volume, 2 = mic volume, 3 = output bass, 4 = output treble, 5 = output volume mute.
Audio mute or
unmute
E
DX^*X%GRPM}
GrpmDX^*X%]
Mute or unmute X% for
group number X^.
Increment value
E
DX^*X&+GRPM}
GrpmDX^*X&]
Increase the value by X&
for group number X^.
Decrement value
E
DX^*X&-GRPM}
GrpmDX^*X&]
Decrease the value by X&
for group number X^.
View master value
E
DX^GRPM}
X*]
View group master value
X*.
Program Volume (Group Master 1)
Set value (dB)
E
D1*X*GRPM}
GrpmD
0
1*X*]
Set the value X* for
group master 1.
Example: ED1*
0
GRPM}
GrpmD
0
1*+
00000
]
Sets the value to 0 dB.
Example: ED1*-1
00
GRPM}
GrpmD
0
1*-
00100
]
Sets the value to -10 dB.
Example: ED1*-1
000
GRPM}
GrpmD
0
1*-
01000
]
Sets the value to -100
dB.
Increment value
E
D1*X&+GRPM}
GrpmD
0
1*X*]
Increase the value X*
by X&.
Decrement value
E
D1*X&-GRPM}
GrpmD
0
1*X*]
Decrease the value X*
by X&.
View master value
E
D1GRPM}
X*]
View current program
volume master value X*.
Mic Volume (Group Master 2)
Set value (dB)
E
D2*X*GRPM}
GrpmD
0
2*X*]
Set the value X* for
group master 2.
Example: ED2*
0
GRPM}
GrpmD
0
2*+
00000
]
Sets the value to 0 dB.
Example: ED2*-1
00
GRPM}
GrpmD
0
2*-
00100
]
Sets the value to -10 dB.
Example: ED2*-1
000
GRPM}
GrpmD
0
2*-
01000
]
Sets the value to -100
dB.
Increment value
E
D2*X&+GRPM}
GrpmD
0
2*X*]
Increase the value X*
by X&.
Decrement value
E
D2*X&-GRPM}
GrpmD
0
2*X*]
Decrease the value X*
by X& .
View master value
E
D2GRPM}
X*]
View master mic volume
value X*.
NOTE:
X% = Audio mute: 0 = no mute, 1 = mute
X^ = Group master number: 1 through 32, groups 1 through 5 are reserved groups, see note above.
X& = Increment and decrement dB values: in 0.1 dB steps (multiply dB by 10, for example 10 = 1.0 dB).
X* = Master volume value: 0 to -100 dB, in 0.1 dB steps, For example 0 = 0 dB, -1 = -0.1 dB,
-10 = -1.0 dB, -100 = -10 dB, -1000 = -100 dB.
See master volume table on page 64 for details
X( = Group member OID number
