Command ASCII Command
(host to switcher)
Response
(switcher to host)
Additional
Description
Input Selection
Select video and
audio input X! ! ChnX!] Select a video and audio
input source X!
View current input ! X!] View currently selected
input source X!.
Select a video input X! & VidX!] Select a video only input
source X!.
View current video
input & X!] View currently selected
video input source X!.
Select an audio
input X! $ AudX!] Select an audio only
input source X!.
View current audio
input $ X!] View currently selected
audio input source X!.
Video Configuration
Set analog video
format X@ *X#\ InpX@•Typ=X#] Set input X@ to X#.
View video format X@ \ X#] View video format X# for
analog input X@.
Video Mute (Output)
NOTE:
Mutes all video: composite, S-video, component, RGB and digital (TMDS).
Video mute 1B Vmt 1] Mute video outputs.
Video unmute 0B Vmt 0 ] Unmute video outputs.
View mute status B 0 or 1] View mute status.
HDMI Audio Mute (Output)
NOTE:
Mutes the embedded audio on the HDMI output.
Audio mute 1Z Amt 1] Mute audio output.
Audio unmute 0Z Amt 0 ] Unmute audio output.
View mute status Z 0 or 1] View output mute status.
Mic Input Mute control
NOTE: This command controls the first gain block of the mic input. See the DSP Configurator Help file for details.
Set mic input mute E M X1# * X4( AU} DsM X1# * X4(] Set the mic input mute
X4( for mic X1#.
View mute value E M X1# AU} X4(] View mic mute value X4(.
Mic Pre-mixer Gain Control
NOTE: This command controls the gain blocks immediately after the ducker blocks. See the DSP Configurator Help file for details.
Set mic value E G X5! * X5$ AU} DsG X5! * X5$] Set the Mic value X5$ for
Mic X5!.
View mic value E G X5! AU} X5$] View value X5$.
NOTE:
X! = Input selection: 0 through 8, 0 = no connection
X@ = Analog input: 1 through 3
X# = Input video format: 1= composite, 2 = S-video, 3= YUV, 4 = RGB (all sync formats), default = RGB
X1# = Mic number (mute inputs): 40000 = Mic 1, 40001 = Mic 2
X4( = Mute status: 0 = mute off, 1 = mute on (default)
X5! = Mic number, 40100 = Mic 1, 40101 = Mic 2
X5$ = Mic value: 0 to -100 dB, in 0.1 dB steps. For example 2048 = 0 dB, 2047 = -0.1 dB, 2038 = -1 dB,
1048 = -10 dB, 1048 = -100 dB, See mic gain table on page 68 for details .
Command Response Table for SIS Commands
MLS 608 D Series • SIS Programming and Control 69
