Programmer’s Guide, cont’d
Integration Seamless Switcher • Programmer’s Guide 4-14
Command/response table for SIS commands (cont’d)
Command ASCII Command Response Additional description
(host to switcher) (switcher to host)
Information requests
Query firmware version number Q x.xx Show the controller firmware
version.
Request part number N zz-zzz-zz Show the ISS’s part #.
Request general information X2 I (See below) Show the ISS’s status.
Vid X1 •Aud X1 •Frz X3 •Hrt X27 •Vrt X27 •Std X28
where: Hrt = horizontal rate (kHz)
and Vrt = vertical rate (Hz).
xxx:xx means the signal is out of range.
The response to the View File Directory command differs, depending on whether the command is
sent via an RS-232 or Telnet connection or sent via a Web browser connection.
View file directory (RS-232) Esc DF filename date/time length
filename date/time length
filename date/time length
filename date/time length
nnnn Bytes Left
View file directory (Web) Esc DF Switcher response
File [1] = ‘filename1, date1, filesize1’;
File [2] = ‘filename2, date2, filesize2’;
File [3] = ‘filename3, date3, filesize3’;
File [4] = ‘filename4, date4, filesize4’;
File [n] = ‘filenamen, daten, filesizen’;
Resets
Zap all audio adjustments Esc zA ZapA Reset all audio levels to 0 dB.
Zap all ISS settings Esc zXXX Zapx Reset all settings :
All inputs: RGB
Ouput: RGBHV 1024x768 @ 60Hz
RGB delay: 1.0 sec.
Audio level: 0 dB
Filtering: Horz. = 3, Vert. = 7
Blanking: 0, top and bottom
Pixel phase: 16
Dissolve speed (duration) 1.0 sec.
Auto Image: Off
Auto Memory recall: On
Absolute reset Esc ZQQQ Zpq Similar to Zap all ISS settings,
plus clears IP address to
192.168.254.254 and deletes user
and administrator passwords.
