4-9 Integration Seamless Switcher • Programmer’s Guide
Command/response table for SIS commands
Command ASCII Command Response Additional description
(host to switcher) (switcher to host)
Input selection
You can select an input for either output (preview or program) using SIS commands.
Select video and audio X2 * X1 ! Out X2 • In X1 • All Select input X1 to X2 output.
Example: 1*2! Out1•In2•All Input 2 video and audio selected
to program output.
Select video only X2 * X1 & Out X2 • In X1 • RGB Select video input X1 to X2
output.
Example: 2*5& Out2•In5•RGB Input 5 video only selected to
preview output.
Select audio only X2 * X1 $ Out X2 • In X1 • Aud Select audio input X1 to X2
output.
Take (switch preview output to program output)
The cut or dissolve effect is determined by the Switching Effect,
X29
(0 = cut, 1 = dissolve) *4#
command. See Command/Response Table for Special Function SIS Commands.
The preview switch mode, stay or swap, determines the preview output after the take command.
• In stay mode, the preview output remains unchanged (both outputs share the same input).
• In swap mode, the program output switches to the preview output (the two outputs swap inputs).
Switch video and audio % Tke0 Switch preview video and audio
output to the program output.
Switch video only 1% Tke1 Switch preview video output to
the program output.
Switch audio only 2% Tke2 Switch preview audio output to
the program output.
The response (Tke0 , Tke1 , or Tke2 ) indicates that the switcher has received and is responding
to the “Take” command. A larger series of switcher-initiated messages follows the Tke response
during a cut or dissolve operation. The following two examples show the sequence of responses to a
“Take” command in stay and swap mode. See Busy (cut and dissolve) earlier in this chapter for
more details about the responses after the Tke response.
Example (stay mode): % Tke0 Take command.
Bsy1 Busy.
Out1•In X1 • All Switch input to program scaler.
Bsy0 Clear busy.
Example (swap mode): 1% Tke1 Take command.
Bsy1 Busy.
Out1•In X1 • All Switch input to program scaler.
Out2•In X1 • All Switch input to preview scaler.
Bsy0 Clear busy.
Video mute
Video mute on X2 *1B X2 Vmt X3 Set the X2 video output to black.
Video mute off X2 *0B X2 Vmt X3 Set the X2 video output to the
selected input 1 through 8.
View video mute status X2 B X3 Video mute is X3 for X2 output.
Input video type
Set video type X1 * X5 \ X1 Typ X5 Specify input X1 video type.
Example: 4*3\ 4Typ3 Specify input 4 type as YUVp.
View video type X1 \ X5 Input X1 video type is X5 .
