HSA 822MS • Introduction HSA 822MS • Introduction
Introduction, cont’d
Pr
eliminary
Pr
eliminary
1-4
The functionality of the HSA 822MS can be optimized with one
through four RGB 580xi AAPs connected to one through four
RGB 580xi Remote Interfaces (figure 1-2).
Projector
Extron
HSA 822MS
Extron
RGB 580xi
Interface
SO G SE RR DD SP V-S YNC W IDT H NE G SY NC CO MP SY NC
CO MPU TE R INPU T SELE CT AU DIO
INP UT S
RG B 5 80x i
AN AL OG AU DIO CO NT RO L VID EO OU TP UT LE VE L A B C D E PE AK ING
Projector
Extron
RGB 580xi SI AAP
Interface
on each side
Extron
HSA 822MS
Surface Access Enclosure
CO MP UTE R INP UT SEL ECT AU DIO
Figure 1-2 — HSA 822MS and RGB 580xi xi xi xi xi
configuration
Features
• Easy access to connectors and controls
• Durable motorized movement
• Motion-limiting safety features to prevent injury and
equipment damage
• A variety of colors of included RJ-45 connector bezels:
black, red, blue, orange, gray, white, ivory, yellow, and
green
• Compact size
• Easy installation of up to four powered or passive double
space Extron AAPs
• RJ-45 (CAT 5/6) network and data connections
• Grounded AC plugs
1-5
