Command
ASCII Command
(host to scaler)
Response
(scaler to host)
Additional Description
On Screen Display (OSD) duration
Select speed
20*
X9*
#
Dur
X9*
]
Set the OSD duration
View speed
20#
X9*
]
View the on screen display time.
Text label (OSD) (Input 4 only)
Write name
E
X8$
NI]
Nam 4
X8$
}
Write text
X8$
for input 4.
Read name
E
NI]
X8$
}
View text label for input 4
PIP size
PIP size
16*
X10%
#
Pmd
X10%
]
Select size of PIP window.
View
16#
X10%
]
View PIP window size.
PIP mode
PIP on
17*
X10)
#
Pip
X10)
]
Turn PIP mode on with PIP window from input
X10)
.
PIP off
17*0#
Pip 0]
Turn PIP mode off.
View
17#
X10)
]
View selection status (on or off).
NOTE:
When PIP is active, all controls apply to the PIP window. The main window cannot be modified while PIP window is displayed.
Swap (when PIP mode is “On”)
%
Tke0]
Swap content between main and PIP window.
PIP mode audio follow (audio model only)
Set
19*
X10^
#
Aud
X10^
]
Select audio follow setting in PIP mode.
View
19#
X10^
]
View audio follow status.
General information
I/i
Vid
X7!
• Aud
X7!
• Typ
X7#
• Std
X8!
• Pre
X8! X8! X8!
• Sdi
X7!
]
Query firmware version
Q/q
x.xx]
View the firmware version.
Query part number
N/n
60-1027-01/-02
/-03/-04]
View the part number.
View internal temperature
20S
X8@
]
View internal temp. in degrees Celsius.
NOTE:
X7! = Input selection
1 to 4
X7# = Input video format
X8! = Input standard
0 = none, 1 = NTSC 3.58, 2 = PAL, 3 = NTSC 4.43, 4 = SECAM, - = RGB or YUVp/HDTV
X8@ = Internal temperature (in degrees Celsius)
X8$ = Text label/preset name
Up to 16 characters
X9* = OSD display setup:
0 to 5 seconds in 1 second steps
X10) = PIP window input selection
0 to 4
X10% = PIP window size
1= 1/4, 2 = 1/9, 3 = 1/16, 4 = 1/25, 5 = side by side normal, 6 = side by side full screen
X10^ = PIP audio setup
1 = follow main, 2= follow PIP, 3 = toggle
DVS 304 Series • SIS Communication and Control
43
