Resolutions and Refresh Rates
Rotate the Adjust horizontal ([) knob while in this submenu to select one of the available
combinations of output resolutions and refresh (vertical scanning) rates.
Rotate the Adjust vertical ({) knob while in this submenu to select one of the available
refresh rates. The default resolution and rate for the DVS 304 series is 1024x768 @ 60Hz.
Resolution 24 Hz 50 Hz 59 Hz 60 Hz 72 Hz 75 Hz 96 Hz 100 Hz 120 Hz
640 x 480 X X X X X X
800 x 600 X X X X X X
852 x 480 X X
1024 x 768 X X X X
1024 x 852 X X X X
1024 x 1024 X X X
1280 x 768 X X X X
1280 x 1024 X X X
1360 x 765 X X X
1365 x 768 X X X
1365 x 1024 X X
1366 x 768 X X X
1400 x1050 X X
1600 x 1200 X X
480p X X
576p X X
720p X X X
1080i X X X
1080p X X X X
1440 x 900 X X
1680 x 1050 X
1280 x 800 X X
1080p Sharp X
1920x1200
* X
1080p CVT X
* DVI models only
Output Format
Using either the Adjust horizontal ([) or Adjust vertical ({) knob, select the output video
format required by the display: RGBHV (default); RGBS; RGsB; Y, R-Y, B-Y.
Sync Polarity
The display device may require a particular combination of horizontal (H) and vertical (V)
sync signal polarities. Select the appropriate combination of positive or negative H and V
sync by rotating either the Adjust horizontal ([) or Adjust vertical ({) knob.
NOTE: If the output format was specified as RGsB or Y, R-Y, B-Y; or RGBS, this
submenu will not be displayed because this menu is only applicable for RGBHV.
DVS 304 Series • Operation 15
