Appendix – drawings – Bell & Gossett S13641B Technologic 5500 Series Pump Controller User Manual
Page 36
36
Appendix – Drawings
Drawing #
Description
1.0
Technologic 5500 Pump Controller - Door
2.0
Technologic 5500 Pump Controller - Subpanel
3.0
Operator Interface and CPU
OPERATOR INTERFACE
LOCAL-REMOTE-OFF
SWITCH
NAMEPLATE
MOUNTED INSIDE DOOR
WARNING LABEL
PART # S11550
NAMEPLATE
MOUNTED INSIDE DOOR
WARNING LABEL
PART # S11550
OPERATOR INTERFACE
LOCAL-REMOTE-OFF
SWITCH
PIN CONNECTOR
WITHOUT BYPASS
WITH BYPASS
TECHNOLOGIC 5500 PUMP CONTROLLER
(FRONT VIEW DOOR CLOSED)
DRAWING 1.0
