Bell & Gossett S13641B Technologic 5500 Series Pump Controller User Manual
Page 16
16
3.12
AFD SETUP
3.12.1
See the following table for all AFD menu items.
AFD MENU ITEMS
Field
Menu Item
Variable
Default
Range
Value
AFD
AFD Min Spd: ###%
30
0-99
Enter the percent speed at which the AFD will operate with the
speed follower signal minimized.
AFD
AFD Max Spd: ###%
100
0-999
Enter the percent speed at which the AFD will operate with the
speed follower signal maximized.
AFD
Reset Tm: ###s
0
0-999
Enter the time it takes the AFD to reset after detecting a self
protecting fault, seconds. Refer to the AFD manufacturer’s
setup manual for proper set up.
AFD
Reset NO.: ##
0
0-10
Enter the number of resets the AFD will attempt after detecting a
self protecting fault prior to determining that the AFD is in the fault
condition. Refer to the AFD manufacturer’s setup manual for
proper set up.
AFD
All PV Fail Spd = ###
100
0-100
Enter the % speed for the drive(s) to operate at in the event
that all zones fail.
AFD
# of Pumps = #
1
0-6
Enter the number of pumps that should operate at the above
speed in the event that all zones fail.
