32

DATA LOGGING MENU ITEMS

Field

Menu Item

Variable

Default

Range

Value

Data Logging

SELECTION: #

0

0-3

Select the log to view.
1 = ALARM LOG
2 = PUMP LOG
3 = DATA LOG
0 = EXIT

Pressing the Next Screen button displays

Alarm Log

DATE TIME ALARM

N/A

MMDD HHMM

" "
" "

The four digit date is displayed in the MMDD format.
The four digit time is displayed in the 24 hour HHMM format.

Pump Log

View Selection #

0

0-2

Select the pump log to view

1 = Pump Run Time.
2 = Pump On/Off Time
0 = Exit

Pump Run Time

Pump Run Time

N/A

P1: # P2: #
P3: # P4: #
P5: # P6: #
The pump run time is displayed in total accumulated
elapsed time in hours.

Pump On/

Pump On/Off

N/A

Off Times

P1: # P2: #
P3: # P4: #
P5: # P6: #
The pump on/off times are displayed in total accumulated times the
pumps are switched on and off.

Signal Log

View Selection #

0

0-3

Select the signal log to view

1 = PV
2 = KWH
3 = Flow
0 = Exit
