19

Field

Menu Item

Variable

Default

Range

Value

AO

Total Avail. AO = O

N/A

0-99

This screen can not be modified. It is here to advise the user of
how many analog outputs can be customized

AO

* AO No: ##

N/A

0-99

Enter the output to be configured as it appears on the wiring diagram.
The analog output card can be configured for 0-10VDC or 4-20mA
signals. Remove the card from the rack, there are two switches below
the pin connector on the back of the card. The bottom switch #1
configures the first analog output. The top switch #2 configures
the second analog output. Select position “U” for 0-10VDC and
position “I” for 4-20mA output signals.

AO

* Code: ###

0

0-255

Enter the code to define the desired functionality of the output.
Valid codes are defined in the Appendix C of this manual.

* NOTE: If a programming error is made, ERROR is shown on the
display. An error is due to reprogramming an input that is currently
used by the system or inputting an undefined code number.
