ASUS KFN5-Q Series 5-31
Press
keys.
2. Information about the volume and its member-disks are then
displayed.
5.3.5 Selecting a boot disk
You can select a boot disk in the SAS Topology screen. This disk is then
moved to scan ID 0 on the next boot, and remains at this position. This
makes it easier to set BIOS boot device options and to keep the boot
device constant during device additions and removals. There can be only
one boot disk.
Follow these steps to select a boot disk:
1. In the SAS BIOS CU, select an adapter from the Adapter List.
2. Select the SAS Topology option.
The current topology is displayed. If the selection of a boot device is
supported, the bottom of the screen lists the Alt+B option. This is the
key for toggling the boot device. If a device is currently configured as
the boot service, the Device Info column on the SAS Topology screen
will show the word “Boot”.
3. To select a boot disk, move the cursor to the disk and press Alt+B.
More keys for the SAS Topology display:
C = Clear Device Mappings for Non-Present Devices
R = Refresh SAS Topology
Enter = On a SAS Enclosure or Expander - Expand or Collapse Item
Enter = On a Disk Drive - Turn on the Locate LED (next key press turns off)
Device Identifier Device
SAS1068105:03:001 Info
Enclosure Controller
Bay 0 SAS
Bay 1 SAS
Bay 2 SAS
Bay 3 SAS
IS VOL
Esc = Exit Menu F1 = Help
Alt+D = Device Properties Alt+N = More Keys
LSI Logic Config Utility v6.08.05.00 (2006.08.02)
SAS Topology -- SAS1068
Direct Attach Drives
RAID Physical Disk
SEAGATE ST373454SS 0003
RAID Physical Disk
RAID Physical Disk
LSILOGICLogical Volume 3000
