6-6 ASUS PCI-DA2200 User’s Manual
RAID 5
8GB
RAID 0
6GB
Logical Drive 1
Logical Drive 0
Partition 0 - 2GB
Partition 1 - 1GB
Partition 2 - 5GB
Partition 0
2.5GB
Partition 1
1.5GB
A drive can be assigned as the Local Spare Drive of one specified
logical drive, or as a Global Spare Drive.
You may divide a logical drive into several partitions, or use the
entire logical drive as one single partition.
2.5GB
2GB
1GB
5GB
1.5GB
LUN 0
LUN 1
Logical Drive 1
Partition 0
Logical Drive 0
Partition 1
ID 0 ID 1
Logical Drive 1
Partition 1
Logical Drive 0
Partition 2
Logical Drive 0
Partition 0
LUN 0
LUN 1
LUN 2
Map each partition to the host SCSI ID. Each SCSI ID will act as one
individual hard drive to the host computer virtually.
Host SCSI Channel
4.5GB
2GB
1GB
5GB
1.5GB
Logical Drive 1
Partition 0
Logical Drive 0
Partition 1
ID 0 ID 2
Logical Drive 1
Partition 1
Logical Drive 0
Partition 2
Logical Drive 0
Partition 0
ID 1 ID 3 ID 4 ID 7
ASUS
PCI-DA2200
RAID Controller
