Asus PCI-DA2200 User Manual
Page 13
3-3
ASUS PCI-DA2200 User’s Manual
RAID 0
Disk Striping
RAID 0 provides the highest performance but no redundancy. Data
in the logical drive is striped (distributed) across several physical
drives.
RAID 1
Disk Mirroring
RAID 1 mirrors the
data stored in one hard drive to another. RAID 1 can only be
performed with two hard drives. If there are more than two hard
drives, RAID (0+1) will be performed automatically.
Block 1
Block 2
Block 3
Block 4
Block 5
Block 6
Block 7
Block 8
.
.
Block 1
Block 3
Block 5
Block 7
Block 2
Block 4
Block 6
Block 8
Striping
Logical Drive
Physical Disks
.
.
.
.
Block 1
Block 2
Block 3
Block 4
Block 5
Block 6
Block 7
Block 8
.
.
Block 1
Block 2
Block 3
Block 4
Mirror 1
Mirror 2
Mirror 3
Mirror 4
Mirroring
Logical Drive
Physical Disks
.
.
.
.
RAID 1
Disks required
2
Capacity
N/2
Redundancy
Yes
RAID 0
Minimum
Disks required
2
Capacity
N
Redundancy
No
