ASUS GUI RAID Manager: Installation

2.3 In-band SCSI

2-13

is "Disabled." If the LCD reads
"Enabled," press and you will
be prompted to accept a change. If the
screen reads “Disabled,” press to
return to the Host-side SCSI
submenu’s.

Press t or s to select "LUN
Application"; and then press .
The default setting is "All Undefine
LUN."

Press and use t or s to select
"Undefine LUN-0’s."

Press to accept. The screen
should display the following message.

The RAID controller adjustments necessary to use In-band SCSI
have been completed. For locally accessing the host computer (see

section 4.10.3.1, Local Connection — SNMP Not Required), all steps

LUN Application-
All Undefine LUN

Applies to ?
Undefine LUN-0’s

LUN Application-
Undefine LUN-0’s
