3-8 ASUS PCI-DA2200 User’s Manual
Flash Selected SCSI Drive
The Read/Write LED of the drive you selected
will light steadily for about one minute.
Flash All SCSI Drives
The Read/Write LED of all connected drives will
light for about one minute. If the LED of the
defective drive did not light on the “Flash
Selected SCSI Drive” function, use “Flash All
SCSI Drives”. The “Flash All SCSI Drives”
function will light LEDs of all the drives except
the defective one.
3.2.3 Automatic Rebuild and Manual
R/W LED
R/W LED
R/W LED
R/W LED
LED Steadily ON
LED Steadily ON
LED Steadily ON
LED Steadily ON
LED Steadily ON
LED Steadily ON
