10-4
Data subject to change without notice 7/07. © 2007 GE Drives
10. AF-300 P11 Replacement Parts (continued)
Catalog No. Rating Drive HP & Quantity per drive
40 50 60 75 100 125 150 200 250 300 350 400 450 500 600 700 800
AF-300 P11 460VAC, 40HP and Above
Main Control Card
EP4113B1
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Gate Driver & Power Supply Card
EP3959C1
1 1
EP3959C2 1
EP3959C3 1 1
EP3959C4 1
EP3959C5 1 1
EP3957C3 1 1
EP3957C4 1 1 1
EP3957C5 1 1 1 1
GATE DRIVE AMPLIFIER CARD
EP4142
3 3 3 3
KEYPAD PANEL
TPAG11S4
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
DC CAPACITOR
LNT2G302MSMAFF 400V 3000µF 4 4
HCGHA2G362N3K 400V 3600µF 4
HCGHA2G452NE3K 400V 4500µF 4 6
HCGHA2G592N3K 400V 5900µf 4 4 6 8 12
HCGHA2G742N3K 400V 7400µF 8 12 12
HCGHA2G932N3KG 400V 9300µF 20 20 26 26
FAN UNIT
FBA09A24H1B0 1 1 1 1 1 2 2 2 3 3 4 4 4 4 4
MRS18-DUL 3 3 4 4
THB1-UHS4556M 4 4
(Standard)
4715PS22TB30
2 2
2750MTP15 2 2 3 3
6250MG1 2 2 3 3 4 4 4
(For NEMA12 Heatsink)
UHS4556MLOT1
2 2
2750MTP15OT1 2 2 3 3
U6250MKG1LTPOT1 2 2 3 3 4 4 4
IGBT MODULE
2MBi150PC14002 3 3
CM200DU24H203 3
2MBi300P14002 3 3
CM200DU24H202 6
2MBi300P14003 6 6 9 9 12 12 12 18 18 24 24
PD6016A 3 3 3 12 12
PD10016A 3 3 6 6 6 12 12 12 24 24 30 30
RECTIFIER MODULE
