10-3

Data subject to change without notice 7/07. © 2007 GE Drives

Catalog No.

Rating

Drive HP & Quantity per drive

1/2

1

2

3

5

7.5

10

15

20

25

30

AF-300 P11 460VAC, 30HP and Below
Main Control Card
G11CPCBB1

1

1

1

1

1

1

1

1

1

1

1

Gate Driver & Power Supply Card
G11PPCBG4004

1

G11PPCBG4008

1

G11PPCBG4015

1

G11PPCBG4022

1

G11PPCBG4037

1

G11PPCBG4055

1

1

G11PPCBG4075

1

G11PPCBG4110

1

G11PPCBG4150

1

G11PPCBG4185

1

KEYPAD PANEL (Only one type per drive)
TPAG11S

NEMA Type1

1

1

1

1

1

1

1

1

1

1

1

TPAG11S4

NEMA Type4

1

1

1

1

1

1

1

1

1

1

1

CAPACITOR UNIT

*

*

G11CAP04

PCB

1

G11CAP05

PCB

1

G11CAP06

PCB

1

G11CAP07

1500µFx2

2

2

G11CAP08

2000µFx2

2

G11CAP09

2700µFx2

2

G11CAP10

3900µFx2

2

G11CAP11

4700µFx2

2

* Located on Gate drive & Power supply Card

FAN

G11FAN01

1

1

1

G11FAN02

1

1

1

2

2

2

POWER MODULE

*

*

PS12046

15A 1200V

1

1

PS12047

25A 1200V

1

6MBP50RS120

50A 1200V

1

1

1

6MBP75RS120

75A 1200V

1

1

6MBP100RS120

100A 1200V

1

* Located on Gate drive & Power supply Card

RECTIFIER MODULE

*

*

*

*

*

PVC7516

75A 1600V

1

1

1

CLK70AA160

70A 1600V

1

1

CLK100AA160

100A 1600V

1

* Located on Gate drive & Power supply Card

CHARGE RESISTOR

*

*

*

*

*

30W200

30W 20WJ

1

1

1

80W100

80W 10WJ

1

1

1

* Located on Gate drive & Power supply Card

FRONT COVER
G11UPCG008P

1

1

G11UPCG040P

1

1

1

G11UPCG075P

1

1

1

G11UPCG220P

1

1

1

10. AF-300 P11 Replacement Parts (continued)
