DeviceNet
420
-
DNetIIOEpr:
Expected packet rate for 110 connections. According to DeviceNet specifications you must set here a value
different from 0, otherwise time-out errors will not be reported. It is expressed in msec. According to DeviceNet
specifications, this value is internally multiplied by 4. Used only for LocalBus.
Default value
=
0 ins.
421
-
SlaveMapLow:
Bit mapped double word for slave_id 0 to 31. If a bit is set to 1, the communication with the corresponding
server is enabled. Used only for LocalBus.
422
-
SlaveMapiligh:
Bit mapped double word for slave_id 32 to 63. If a bit is set to 1, the communication with the corresponding
server is enabled. Used only for LocalBus.
430
-
DN#RxPLC:
Valid only for “Predefined Master/Slave Connection Set” (PLC). This is the number of bytes received by the
DGFC from the master. Must be set when a Bricks program is executed. It’s calculated when Bricks program is
not executed (see relative chapters). This parameter is analyzed at power-on only.
431
-
DN#TxPLC:
Valid only for “Predefined Master/Slave Connection Set” (PLC). This is the number of bytes transmitted by the
DGFC to the master. Must be set when a Bricks program is executed. It’s calculated when Bricks program is not
executed (see relative chapters). This parameter is analyzed at power-on only.
Liz.
CONFIGURATION PARAMETERS
