12 Specifications
Galaxy Power System 4827 Specifications
AC input table
This table is for 3-wire AC input systems only. It is based on U.S. National Electric Code – Local codes supersede.
For 4-wire system or systems in other countries, follow local country codes.
Code
Nameplate Rating
(input current) External circuit
breaker Conduit
Qty. & size Wire size
based on
75:C rating Ground wire
based on
75:C rating Wire and
ground
lugs
Size Qty.
G021 1 AC Feed at 13A,
200 VAC 150A (1) 3- Pole (1) 2” (1/Bay) (3) 1/0 GA (1) 6 GA provided
G022 2 AC Feeds at 13A,
200 VAC 150A (2) 3-Pole (2) 2” (1/Bay) (6) 1/0 GA (2) 6 GA provide
G026 12 AC Fe ds at 15A
each, 200 VAC 20A (12) 2-pole (1) 2” (1/Bay) (24) 8 GA (1) 8 GA provided
12 AC Feeds at 15A
each, 200 VAC 20A (12) 2-pole (1) 1.5” (1/Bay) (24) 8 GA (2) 8 GA provided
12 AC Feeds at 15A
each, 200 VAC 20A (12) 2-pole (4) 1” (1/Bay) (24) 10 GA (4) 8 GA provided
6 AC Feeds at 30A
each, 200 VAC 40A (6) 2-pole (2) 1” (1/Bay) (12) 8 GA (2) 8 GA provided
G027 24 AC Feeds at 15A
each, 200 VAC 20A (24) 2-pole (3) 2” (1/Bay) (48) 8 GA (3) 8 GA provided
24 AC Feeds at 15A
each, 200 VAC 20A (24) 2-pole (6) 1.5” (1/Bay) (48) 10 GA (6) 8 GA provided
24 AC Feeds at 15A
each, 200 VAC 20A (24) 2-pole (8) 1” (1/Bay) (48) 10 GA (8) 8 GA provided
12 AC Feeds at 30A
each, 200 VAC 40A (12) 2-pole (4) 1” (1/Bay) (24) 8 GA (4) 8 GA provided
8 AC Feeds at 45A
each, 200 VAC 60A (8) 2-pole (2) 1.5” (1/Bay) (16) 4 GA (2) 6 GA provided
G028 36 AC Feeds at 15A
each, 200 VAC 20A (36) 2-pole (4) 1.5” (1/Bay) (72) 8 GA (4) 8 GA provided
36 AC Feeds at 15A
each, 200 VAC 20A (36) 2-pole (3) 2” (1/Bay) (72) 8 GA (3) 8 GA provided
36 AC Feeds at 15A
each, 200 VAC 20A (36) 2-pole (9) 1” (1/Bay) (72) 10 GA (9) 8 GA provided
18 AC Feeds at 30A
each, 200 VAC 40A (18) 2-pole (3) 2” (1/Bay) (36) 4 GA (3) 6 GA provided
12 AC Feeds at 45A
each, 200 VAC 60A (12) 2-pole (3) 2” (1/Bay) (24) 2 GA (3) 6 GA provided
